| System |
|
| Main Processor |
Multi-core embedded processor |
| Operating System |
Embedded LINUX |
| Video and Audio |
|
| Max IPC Input |
8CH |
| Two-way Talk |
Support |
| Audio Compression |
G.711u |
| Live View |
|
| Display Split |
1/4/8 CH |
| Resolution |
8MP (3840*2160) / 5MP (2592*1944) / 2MP (1920*1080) /
1.3MP (1280*1024) / 1MP (1280*720) / SVGA (1024*768)
|
| Live View Capability |
4CH@8MP(25/30fps) / 8CH@D1((25/30fps) |
| Recording |
|
| Video Compression |
H.265+ / H.265 / H.264 |
| Recording Resolution |
4K/5MP/3MP/1080P/960P/720P/D1/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Max. Decoding Capability |
8MP@25/30fps |
| Incoming Bandwidth |
128Mbps |
| Bit rate |
Main Stream: 256Kbps ~ 8192Kbps Sub Stream: 50Kbps ~ 700Kbps |
| Record Mode |
Schedule, Manual, Motion Detection, IVA Events Alarm |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Playback and Backup |
|
| Playback Channel |
8CH Synchronously Playback |
| Search Mode |
Time/ Date, Alarm Types, IVA Search, Face retrieval |
| Playback Function |
Play, Stop, Play Forward, Play Backward, 30 Seconds Forward, 30 Seconds Backward, Fast Play, Slow Play, Single Frame Play, Hide/Show Time Bar, Backup, Snapshot, Full Screen |
| Backup Mode |
USB Device / Network Remote |
| Facial Recognition |
|
| Performace |
8 CH face recognition with face detection camera
4 CH facial recognition with regular camera
|
| Face Processing Speed |
up to 25 Faces/Second |
| Face Templates |
50,000 pictures |
| Face Library |
Black List/White List/Other List |
| Facial Recognition Channels |
8CH |
| Alarm Linkage Actions |
Recording/Buzzer/Monitoring/Center/FTP Upload/Email |
| Create Face Templates |
Capturing by Preview/Import, App collect (Antarview Pro)/VMS (AntarVis 2.0)
Face Database by USB Device
|
| Search by Face |
Support |
| IVA Alarm |
|
| Local IVA Functions |
Line Crossing / Target Counting / Object Left/ Lost / Intrusion / Scene Change / VQD |
| Regular Detection |
Motion Detection / Video Shelter / Video Loss |
| AI Search |
Support search target video by multiple intelligent conditions |
| Network |
|
| Network Protocol |
TCP/IP, HTTP, DDNS, SMTP(SSL), DHCP, PPPoE, UPnP, NTP, P2P, ONVIF |
| Max. Online User |
5 |
| Web Browser |
IE / Google Chrome / Firefox / Safari |
| Operation System |
Windows |
| Management Platform |
AntarVis 2.0 / ZKBioSecurity IVS / BioAccess IVS |
| Mobile Application |
AntarView Pro (iOS & Android) |
| P2P Cloud Service |
Support |
| Interoperability |
ONVIF Profile S, SDK, CGI, API |
| Storage & Auxiliary Interface |
|
| SATA Ports |
2 SATA Ports, Up to 8 TB capacity for each HDD |
| eSATA |
N/A |
| Raid 0/1/5/6/10 |
N/A |
| HDMI |
1*HDMI (4K) |
| VGA |
Support |
| Network Interface |
2 RJ-45 Ports (10/100/1000Mbps) |
| PoE Ports |
N/A |
| USB |
2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 ) |
| Audio Input/Output |
43,831 |
| Alarm Input/Output |
43,925 |
| RS-485 |
Support |
| Power |
|
| Power Supply |
DC 12V/3A |
| Power On/Off Switch |
N/A |
| Power Consumption |
20W (without HDD) |
| General |
|
| Casing |
1.5U |
| Working Temperature |
-10°C ~ 55°C / 14°F ~ 131°F |
| Working Humidity |
10% ~ 90% |
| Dimensions (L*W*H) |
325 * 246 * 50 (mm) |
| Net Weight |
2.5kg (without HDD) |
| Gross Weight |
3kg (without HDD) |
