| Image Sensor |
5 MP CMOS image sensor |
| Max. Resolution |
2560 (H) × 1944 (V) |
| Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
|
| Day & Night |
ICR |
| Angle Adjustment |
Pan: 0 to 360°, Tilt: 0 to 75°, Rotation 0 to 360° |
| Signal System |
PAL/NTSC |
| Lens Type |
2.4 mm, 2.8 mm, 3.6 mm, 6 mm fixed lens |
| Focal Length & FOV |
2.4 mm, horizontal FOV: 110°, vertical FOV: 81°, diagonal FOV:137°
2.8 mm, horizontal FOV: 85°, vertical FOV: 63°, diagonal FOV:110°
3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105°
6 mm, horizontal FOV: 57°, vertical FOV: 43°, diagonal FOV:72°
|
| Lens Mount |
M12 |
| Image Parameters Switch |
STD/HIGH-SAT |
| Image Settings |
Brightness, Sharpness, DNR, Mirror, Smart IR |
| Frame Rate |
TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps
AHD: 5M@20fps, 4M@30fps, 4M@25fps
CVI: 4M@30fps, 4M@25fps
CVBS: PAL/NTSC
|
| Day/Night Mode |
Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Image Enhancement |
BLC, HLC |
| White Balance |
ATW/MANUAL |
| AGC |
Support |
| Video Output |
Switchable TVI/AHD/CVI/CVBS |
| Material |
Plastic |
| Dimension |
Φ 84.6 mm × 78.9 mm (Φ 3.33" × 3.11") |
| Weight |
Approx. 143 g (0.32 lb.) |
| Operating Condition |
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Communication |
HIKVISION-C |
| Language |
English |
| Power Supply |
12 VDC ±25% |
| Consumption |
Max. 4.3 W |
| IR Range |
Up to 20 m |
