Image Sensor |
1/3" Progressive Scan CMOS |
Max. Resolution |
2688 × 1520 pixels |
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
Lens Options |
2.8mm, 4mm, 6mm (Fixed focal lengths) |
Lens Mount |
M12 |
Aperture |
F1.6 |
IR Illuminator |
Yes (IR Wavelength: 850nm) |
Main Stream Frame Rates |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
Video Compression |
Main stream: H.265/H.264/H.264+/H.265+
Sub-stream: H.265/H.264/MJPEG
|
Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 8 Mbps |
WDR (Wide Dynamic Range) |
120 dB |
Image Enhancement |
BLC, HLC, 3D DNR |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage |
Built-in microSD, up to 512 GB |
Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, and more |
Simultaneous Live View |
Up to 6 channels |
User/Host |
Up to 32 users with 3 user levels |
Security |
Password protection, HTTPS encryption, IP address filter |
Operating Temperature Range |
-30 °C to 60 °C (-22 °F to 140 °F) |
Material |
Aluminum alloy body, plastic sun shield, IR cover |
Dimensions |
Ø105 × 299.7 mm (Ø4.1" × 11.8") |
Weight |
Approx. 1070 g (2.4 lb.) |
Language Options |
33 languages available |
General Function |
Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
Protection |
IP67 (Dust and water resistance) |
Certifications |
EMC, Safety, Environment (CE, UL, FCC, RoHS, WEEE, and more) |
