Image Sensor |
1/3" Progressive Scan CMOS |
Max. Resolution |
2560 × 1440 |
Min. Illumination |
Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light |
Shutter Time |
1/3 s to 1/100,000 s |
Day & Night |
24/7 color imaging |
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Lens Type |
Fixed focal lens, 2.8mm and 4mm optional |
Focal Length & FOV |
- 2.8mm: Horizontal FOV 96°, Vertical FOV 52°, Diagonal FOV 113° <br> - 4mm: Horizontal FOV 75°, Vertical FOV 40°, Diagonal FOV 89° |
Lens Mount |
M12 |
Iris Type |
Fixed |
Aperture |
F1.0 |
Depth Of Field |
- 2.8mm: 2 m to ∞ <br> - 4mm: 2.7 m to ∞ |
DORI |
- 2.8mm: D: 64 m, O: 25 m, R: 12 m, I: 6 m <br> - 4mm: D: 82 m, O: 32 m, R: 16 m, I: 8 m |
Illuminator |
Supplement Light Type: White Light |
Supplement Light Range |
Up to 30 m |
Smart Supplement Light |
Yes |
Main Stream |
50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720) <br> 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720) |
Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) <br> 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 <br> Sub-stream: H.265/H.264/MJPEG |
Wide Dynamic Range (WDR) |
120 dB |
SNR |
≥ 52 dB |
Day/Night Switch |
Day, Night, Auto, Schedule |
Image Enhancement |
BLC, HLC, 3D DNR |
Privacy Mask |
4 programmable polygon privacy masks |
Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
Built-In Microphone |
Yes |
Reset Key |
Yes |
Power |
- 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug <br> - PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
Material |
Aluminum alloy body |
Dimension |
Ø76.6 mm × 164.4 mm (Ø3 × 6.5") |
Package Dimension |
234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6") |
Weight |
-L: Approx. 410 g (0.9 lb.); -LUF: Approx. 430 g (0.9 lb.) |
With Package Weight |
-L: Approx. 630 g (1.4 lb.); -LUF: Approx. 650 g (1.4 lb.) |
Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
Language |
English, Ukrainian |
General Function |
Heartbeat, anti-banding, mirror, password protection, password reset via email |
Approval |
EMC: FCC, CE-EMC, RCM, KC |
