Camera |
Image Sensor |
1/2.7" Progressive Scan CMOS |
Shutter Speed |
Self-adaptive shutter |
Lens |
4mm @ F2.0, viewing angle: 46° (Vertical), 89° (Horizontal), 104° (Diagonal) 6mm @ F2.0, viewing angle: 28° (Vertical), 52° (Horizontal), 60° (Diagonal) |
PT Angle |
Pan: 350°, Tilt: 80° |
Minimum Illumination |
0.5 Lux @ (F1.6, AGC ON), 0 Lux with IR (Data is obtained from EZVIZ laboratories) |
Lens Mount |
M12 |
Day & Night |
IR-Cut filter with auto-switching |
DNR |
3D DNR |
WDR |
Digital WDR |
Night Vision Distance |
30 m / 98 ft |
Video & Audio |
Max. Resolution |
1920 × 1080 |
Frame Rate |
Max: 30fps; Self-Adaptive during network transmission |
Video Compression |
H.265 / H.264 |
H.265 Type |
Main Profile |
Video Bit Rate |
Full HD; Hi-Def; Standard. Adaptive bit rate. |
Audio Bit Rate |
Self-Adaptive |
Max. Bitrate |
2 Mbps |
Network |
Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
Channel Bandwidth |
Supports 20 MHz |
Transmission Rate |
11b: 11 Mbps,11g: 54 Mbps,11n: 72 Mbps |
Wi-Fi Pairing |
AP pairing |
Protocol |
EZVIZ Cloud Proprietary Protocol |
Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
Storage |
Local Storage |
MicroSD card slot (Up to 512GB) |
Cloud Storage |
EZVIZ Cloud Storage (Subscription Required) |
Function |
Smart Alarm |
AI-Powered Human Shape Detection |
Customized Alert Area |
Supports |
Two-way Talk |
Supports |
General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
General |
Operating Conditions |
-30 °C to 50°C ( -22 °F to 122 °F ), humidity 95% or less (non-condensing) |
IP Grade |
Weatherproof Design |
Power Supply |
DC 12V / 1A |
Power Consumption |
MAX. 12W |
Dimensions |
100.05 × 129.19 × 149.75 mm (3.94 × 5.09 × 5.9 inch) |
Packaging Dimensions |
140 × 140 × 192 mm (5.51 × 5.51 × 7.56 inch) |
Weight (With package) |
730 g (25.75 oz) |
Net Weight |
420 g (14.8 oz)
|
