IP Phone & PBX Zycoo CooVox-U50
Zycoo CooVox-U50
Zycoo CooVox-U50Zycoo CooVox-U50

Zycoo CooVox-U50

not inserted
Price 0
Status In stock
Product Code PR01099
Brand ZYCOO
Model U50
Features

    •  Quick Setup Wizard
    • Endpoints Provisioning
    • Extension Web Portal (WebRTC Integrated)
    • SIP Proxy Services
    • Billing With a built-in billing system
    • Web Conference Manager



Hotline: 01979234344 | Corporate: 01979234319
Download Brochure
Share On :
Last Modified On: 07-02-2023

Zycoo CooVox-U50 is an affordable, scalable, interoperable, secure and reliable solution and provides not only traditional PBX features such as Automated Attendant and Voicemail, but also many advanced features including Remote Extensions, Remote Office Connections, Conference Bridge, Call Recording, etc. It is an ideal choice for small and medium-sized companies under 100 employees who wish to build their own innovative business phone systems. CooVox-U50 is designed to meet the telephony needs of a modern business and will greatly increase their efficiency and competitiveness.



✓ Quick Setup Wizard allows speedy initial configuration of the U50 system. The wizard includes all essential configuration steps in an easy-to-use and intuitive web-based interface.

✓ Endpoints Provisioning Quick and simple deployment of endpoint devices using PNP and Quick Register Code. CooCall APP can be provisioned by scanning a QR code.

✓ Extension Web Portal (WebRTC Integrated) Thanks to the extension web portal, you can now Playback voicemail/recordings online, make/receive phone calls, click to dial, incoming call pop-ups, send the fax. All of this is from within your web browser without installing any plugins.  Hardware Specifications

✓ SIP Proxy Services No fixed public IP, third-party DDNS services, and VPN router is required. Remote extension and remote branch office phone system integration have never been easier!

✓ Billing With built-in billing system, no third-party billing software is required. Prepaid/postpaid billing, billing credit, flexible billing rates, and billing statistics features are all supported.

✓ Web Conference Manager By using web conference manager, it will be much easier for you to start and manage a conference from the Web interface. Invite participants, mute/unmute participants, kick out participants can be done with a few mouse clicks. Items Specifications Telephony Interfaces 8xFXO/FXS/GSM/WCDMA Interfaces CPU 1GHz ARMv7 Processor SDRAM 1GB DDR3 Storage 16GB SD Card USB (Extended Storage Supported) 1 (Supported File System: FAT16, FAT32, EXTFAT, NTFS, EXT3, EXT4) Ethernet Interface WAN, LAN (10/100Mbps) Power DC 12V, 2A Dimension 345x160x35mm (Rack mount or Desktop based) ✓ Operator Panel The Operator Panel is a comprehensive software application specially designed for the CooVox series of IPPBX. By using the Operator Panel, users can achieve features such as live paging, emergency paging, high-quality background music, scheduled paging, scheduled music, etc.

Telephony Interfaces 8xFXO/FXS/GSM/WCDMA Interfaces
CPU 1GHz ARMv7 Processor
SDRAM 1GB DDR3
Storage 16GB SD Card
USB (Extended Storage Supported)  1 (Supported File System: FAT16,FAT32,EXTFAT,NTFS,EXT3,EXT4)
Ethernet Interface WAN, LAN (10/100Mbps)
Power DC 12V, 2A
Dimension 345x160x35mm (Rack mount or Desktop based)
System Capacity

✓ 100 Extensions ✓ Unlimited IVR Levels

✓ 30 Simultaneous Calls ✓ 50 SIP/IMS Trunks (Max)

✓ 30 Conference Attendees ✓ 500000 CDR History

✓ 150hrs Recording/Voicemail(Internal Storage) ✓ 10000 Phonebook Contacts

✓ 1-6 EX16S Deployment (Recommended) ✓ 30 Paging Members

Protocols & Codecs

✓ SIP(RFC3261), IAX2

✓ DTMF(RFC4733, SIPINFO, In-Band)

✓ Transport Protocols: UDP, TCP, TLS, SRTP

✓ Network Protocols: IPv4, IPv6, VLAN, DHCP, PPPoE, NTP, SNTP, TFTP, SSH, HTTPS, LDAP

✓ Video Codecs: VP8, H.264, H.263+, H.263, H.261

✓ Audio Codecs: Opus, G.722, G.711(a-law, u-law), G.729, G.726, GSM, SPEEX, AMR, ARM-WB

Telephony Features

✓ Call Queue ✓ IVR (Multi-layer) ✓ DISA

✓ Time Conditions ✓ Ring Group ✓ Caller ID

✓ Smart DID ✓ Paging & Intercom ✓ Call Forward

✓ Call Spy ✓ Blacklist ✓ One Number Stations

✓ Call Transfer ✓ Video Call ✓ Voicemail

✓ Music On Ringback ✓ Call Pickup ✓ 3-way Calling

✓ Wakeup Call ✓ Distinctive Ringtone ✓ Call Parking

✓ Conference Call ✓ PIN Code ✓ Auto Call Recording

✓ Call Waiting ✓ Follow Me ✓ Do Not Disturb

✓ One Touch Recording ✓ Speed Dial ✓ Call Back

✓ Switch Call ✓ Call Detailed Records (CDR)

Feature Highlights

✓ Quick Installation Guide ✓ SIP Proxy (NAT Traversal)

✓ Softphone APP Auto Provisioning (QR Code Scan) ✓ Voicemail to Email

✓ IP Phone Auto Provisioning (PNP, Quick Register Code) ✓ Fax to Email

✓ LDAP Phonebook Auto Configure (H81, H83) ✓ Multilingual Web UI

✓ EX16S Auto Provisioning ✓ Multilingual Voice Prompts

Multi-level User Administration

✓ Admin user: All Privileges. ✓ Billing user

✓ Operator user: Extensions, faxes, CDR,recordings, etc. ✓ Conference manager

✓ Extension user: WebRTC, recordings, voicemails, call logs, etc.

Security

✓ Firewall based on iptables ✓ IP Black/White List

✓ Intrusion auto detection and prevention ✓ Extension Permit IP

✓ Geo-IP (Security policy based on IP address geographical location)

Network Features

✓ Network (WAN): Static IP, DHCP, PPPoE ✓ DDNS (Dynamic Domain Name Server)

✓ VPN: PPTP, OpenVPN, IPSec, L2TP ✓ VLAN (WAN & LAN Interface) (Server and Client)

✓ Virtual IP ✓ Static Routing

✓ Local Domain Name Services ✓ DHCP (Server and Client) ✓ SIP Proxy (NAT Traversal)
