Image Sensor |
1/2.7" Progressive Scan CMOS |
Max. Resolution |
2592 × 1944 |
Min. Illumination |
Color: 0.017 Lux @ (F2.25, AGC ON), B/W: 0 Lux with IR |
Lens |
Fixed focal lens, 1.05 mm |
Focal Length & FOV |
1.05 mm, Horizontal FOV: 180°, Vertical FOV: 180°, Diagonal FOV: 180° |
Lens Mount |
M12 |
Aperture |
F2.25 |
Illuminator |
IR |
Supplement Light Range |
Up to 8 meters |
Smart Supplement Light |
Yes |
IR Wavelength |
850 nm |
Computing Power |
1.5 TOPS |
Deep Learning Structure |
Caffe; PyTorch; TensorFlow |
Video Compression |
H.265/H.264/H.264+/H.265+ (Main Stream), H.265/H.264/MJPEG (Sub-stream), H.265/H.264 (Third Stream), H.265/H.264/MJPEG (Fourth Stream) |
Video Bit Rate |
32 Kbps to 16 Mbps |
WDR |
120 dB |
Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
Network Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SFTP, ARP, SNMP |
Simultaneous Live View |
Up to 6 channels |
API |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface, memory card encryption, SFTP encryption, SRTP encryption |
Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
Day/Night Switch |
Day, Night, Auto, Schedule |
Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port, Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB, Built-In Microphone, Audio input/output, 1 input, 1 output (max. 12 VDC, 30 mA), RS-485, Reset Key |
Deep Learning Function |
Face Capture |
Power |
12 VDC ± 25%, 0.50 A, max. 6 W (Coaxial power plug), PoE: 802.3af, Class 3, 36 V to 57 V, 0.20 A to 0.13 A, max. 7.5 W |
Dimensions |
Ø119.9 mm × 41.2 mm (Ø4.7 × 1.6") |
Weight |
Approx. 320 g (0.7 lb.) |
Language |
33 languages supported |
Approval |
EMC, Safety, Environment compliant |
